Required Outbound Ports from Field
Open firewall outbound policy, allows Gateway connect to below IP address.
Please turn off TLS Proxy or SSL Inspection features on firewall.
| URL | IP Address | Port | Notes |
|
api.neoedgecentral.com |
13.215.152.84/32 |
443/tcp |
Gateway connect to NeoEdge Central |
|
mqtt.neoedgecentral.com |
46.137.251.151/32 18.140.80.229/32 |
8883/tcp |
Gateway connect to NeoEdge Central |
For NeoFlow deployment, open firewall outbound policy, allows Gateway connect to below IP address.
| URL | IP Address | Port | Notes |
| docker image register |
99.83.128.0/17 75.2.0.0/17 103.246.148.0/23 122.248.192.0/18 13.144.0.0/16 13.150.0.0/15 13.212.0.0/15 13.214.0.0/15 13.228.0.0/15 13.248.0.0/15 13.250.0.0/15 13.251.0.0/15 136.18.0.0/15 141.230.0.0/16 141.231.0.0/16 15.177.82.0/24 15.193.160.0/22 15.193.2.0/24 15.220.192.0/22 15.220.240.0/21 15.221.0.0/15 15.230.0.0/15 15.248.141.0/24 150.222.0.0/15 151.148.38.0/24 16.12.48.0/21 16.156.0.0/15 16.57.0.0/18 172.106.0.0/15 173.83.219.0/24 175.41.128.0/18 18.136.0.0/16 18.138.0.0/15 18.140.0.0/15 18.141.0.0/15 18.142.0.0/15 18.143.204.64/26 18.99.32.0/19 203.83.220.0/22 3.0.0.0/15 3.4.0.0/15 35.50.0.0/15 35.55.0.0/15 35.71.118.0/24 43.250.192.0/24 43.250.193.0/24 45.57.128.0/18 46.137.192.0/19 46.137.224.0/19 46.51.216.0/21 47.128.0.0/14 47.129.81.64/26 47.129.90.0/24 47.130.7.128/25 52.119.184.0/22 52.119.205.0/24 52.144.0.0/15 52.219.0.0/15 52.220.0.0/15 52.74.0.0/16 52.76.0.0/17 52.76.128.0/17 52.77.0.0/16 52.93.0.0/15 52.94.0.0/15 52.95.0.0/15 54.151.128.0/17 54.169.0.0/16 54.179.0.0/16 54.239.0.96/28 54.240.0.0/15 54.251.0.0/16 54.254.0.0/16 54.255.0.0/16 56.10.0.0/16 56.11.0.0/16 64.252.0.0/15 69.107.0.0/15 96.0.0.0/15 99.151.104.0/21 99.77.0.0/15 99.82.173.0/24 99.83.102.0/24 99.83.104.0/24 99.87.0.0/22 13.213.20.144/28 13.213.20.160/28 3.5.146.0/23 3.5.148.0/22 |
443/tcp | To download necessarry files for docker images. |
