NeoFlow Message Payload Notice

NeoFlow automatically generates and sends a message to the IT Service based on the data source you provide, the defined data flow, conditions, and send time. Due to the variation in these settings, the content of the NeoFlow message will also differ. This article explains the structure of the NeoFlow message payload to assist your IT Service in interpreting it.

NeoFlow Message Example

{
    "Tag_Boolean_1": {
        "Value": true,
        "Timestamp": "2024-10-07T05:12:17.848+00:00"
    },
    "Tag_Boolean_2": [
        {
            "Value": true,
            "Timestamp": "2024-10-07T05:12:15.848+00:00"
        },
        {
            "Value": true,
            "Timestamp": "2024-10-07T05:12:16.849+00:00"
        }
    ],
    "Tag_Float_1": {
        "Value": -3.807666e-10,
        "Timestamp": "2024-10-07T05:12:17.852+00:00"
    },
    "Tag_Float_2": [
        {
            "Value": 1.858497,
            "Timestamp": "2024-10-07T05:12:15.85+00:00"
        },
        {
            "Value": 1.832256,
            "Timestamp": "2024-10-07T05:12:16.85+00:00"
        }
    ],
    "Tag_String_1": {
        "Value": "Hello World! [08793]",
        "Timestamp": "2024-10-07T05:12:17.85+00:00"
    },
    "Tag_String_2": [
        {
            "Value": "Hello World! [08791]",
            "Timestamp": "2024-10-07T05:12:15.848+00:00"
        },
        {
            "Value": "Hello World! [08792]",
            "Timestamp": "2024-10-07T05:12:16.849+00:00"
        }
    ],
    "Timestamp": "2024-10-07T05:12:25.362+00:00",
    "project": "Demo"
}

The above message contains 8 tags.
